Roland SPD1K

SPECIFICATION

SInstruments22User SampleNumber of User Sample: 1

Sound Length: 5seconds

Data Format: WAV (44.1 kHz, 16 bits, Mono/Stereo)ControlsINST knob

[TUNING] knob

[FX] knob

[VOLUME] knob

[INST VARIATION] button

[THRES] knob

[SENS] knob

[POWER] switchEffectsReverb, DistortionIndicatorTRIG IndicatorConnectorsOUTPUT (MONO) jack: 1/4-inch phone type

PHONES jack: Stereo 1/4-inch phone type

USB port: Micro-B type

DC IN jackUSBMIDI

Mass Storage ClassPower SupplyRechargeable Ni-MH battery (AA, HR6) x 4

Alkaline battery (AA, LR6) x 4

AC adaptor (DC9V)Current Draw300 mA (DC IN)

*Expected battery life under continuous use

Rechargeable Ni-MH battery (AA, HR6):

Normal use: Approx. 7 hours

Maximum load use: Approx. 4 hours

Alkaline battery (AA, LR6):

Normal use: Approx. 6 hours

Maximum load use: Approx. 3 hours

*These can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.AccessoriesOwner's manual

Leaflet "USING THE UNIT SAFELY"

Attachment

Attachment screws x 2

Holder mounting screws (bolt x 1, nut x 1, washers x 2)

*Acceptable rod diameters: 8.0–12.7 mm (3/8–1/2 inches)

Alkaline batteries (AA, LR6) x 4Options (sold separately)AC adaptor: PSA-S series

Personal drum monitor: PM-10

Headphones: RH-300VSIZE AND WEIGHTWidth140 mm

5-9/16 inchesDepth160 mm

6-5/16 inchesHeight56 mm

2-1/4 inchesWeight900 g

2 lbs
